Features

1/3" Sony Super HAD CCD

Up-Most High Resolution: 550 TV Lines

Built-in Next Generation 3D DNR with 3D Filter

Max. Sens-Up (x258), 0.00001 Lux of Min. Illumination

Convenient OSD Control Function

x32 Digital Zoom

Free Area Selectable Function of BLC & MD

Privacy Color Masking for 8 Area Selection

Camera OSD Controlled by RS-485 (Optional)

ICR-IR Infrared Cut Filter Removable (Optional)

Max 70% of DIsk Saving Effect with Super DNR

Negative Image Function

Digital Wide Dynamic Range Function (D-WDR)

Dual Power (AC 24V / DC 12V)- Optional

Specification

Image Pick-up Device 1/3" Sony Super HAD CCD Picture Element 811(H) * 508(V) Effective Pixels 768(H) * 494(V) Scanning System 2:1 Interlace Synchronization Internal/Line Lock OSD Available Backlight BLC/HSBLC/Off Selectable Resolution 550 TV Lines S/N Ratio 52 dB (AGC Off, Weight On) Minimum Illumination 0.00001 Lux (Sens-Up * 258) Gain Control High, MIddle, Low, Off Selectable 3 DNR Off/On (1~50 Level Adjustable) D-WDR Indoor / Outdoor / Off Motion Detection On/Off (4 Zone, Alarm Output) Privacy On/Off (8 Zone) Mirror Off/Mirror/V-Rev/Rotate Freeze On/Off Sharpness 0~31' (Level Adjustable) D&N Slection Color/BW/Auto Digital Zoom On (*32) / Off Blemish Compensation 256 Point (Even 128 Point, ODD 128 Point) Power Consumption 120 mA Lens DC Auto Iris Varifocal Lens (2.8mm~12mm) Operating Temperature -10c ~ +50c RH, 95% Max. Storage Temperature -20c ~ +60c, RH 95% Max. Dimension 140mm(W) * 100mm(H) * 140mm(D) Weight 900g
