Features
H.264 compression ideal for saving HDD space
Real time live display
Up to 120FPS @ 360x240(CIF) Recording
Live display, record, backup, playback and network access at the same time
Control methods: front panel, USB mouse, IR remote controller, client viewer
Intuitive GUI for easy configuration and menu driven operation1 channel audio recording and playback
Supports (HDD OPTIONAL) PICK FROM ABOVE - 1 SATA HDDPan / Tilt / Zoom camera controlData backup: USB devices, network
Event triggered with email notification: motion detection, alarm, video loss
Support Internet Explorer with same GUI as DVR site
Multi-language OSD
Central Management System (CMS) supports up to 16 DVRs
3G/GPRS mobile phone monitoring
Specification
CONNECTOR
Video System NTSC
Video Input 4-CH BNC
Loop N/A
Video Output 1-CH BNC
SPOT Output 1-CH Bnc
VGA Output 1024x768 (Optional)
S-Video Output N/A
Audio Input 1-CH RCA
Audio Output 1-CH RCA
Audio Backup YES
Sensor 4 Inputs/1 Output
RS-232 N/A
RS-485 Pan/Tilt/Zoom Camera
USB Port 1
Mouse USB Mouse
IR Remote Controller YES
STORAGE
HDD Support (HDD OPTIONAL) SATA HDD x 1 (Max. 1TB)
CD Writer N/A
DVD Writer N/A
OSD
Display Divison 1,4
GUI YES
Title 14 Characters
Digital Zoom 2X
Recording
Video Compression H.264
Resolution 720x480, 720x240, 360x240
Frame Rate 30, 60, 120
Qualiy Highest, High, Normal, Low, Lowest
Record Mode Manual, Schedule, Event(motion detection/sensor)
Pre-Alarm Recording 16MB (10 sec)
Post-Alarm Recording 1-999 sec
Motion Detection 16X12 (sensitivity 1~15)
Watermark Proof N/A
PLAYBACK
Search Mode Time, Event
Playback Speed fast forward/backward 2X/4X/8X/16X/32X/64X
slow forward/backward 1/2X,1/4X,1/8X,1/16X
play/pause
Backup Mode USB Flash Driver/Network
NETWORK
Network Compression H.264
Software NO
Internet Explorer YES
Firefox NO
Network Users 4
Remote Notification E-mail Message
Service TCP/IP, SMTP, DHCP, DDNS, PPPoE
OTHER
Daylight Saving YES
Password 5 users including 1 administrator
user authority selectable
Key Lock YES
Keyboard Controller N/A
Firmware Update USB Device
Dimension 188mm (W) x 54mm (H) x 209mm (D)
Power Source DC12V
Features Central Management System (CMS) supports up to 16 DVRs
3G/GPRS mobile phone monitoring
|
