Features

- Simultaneous MPEG-4 and Motion JPEG video stream - Excellent Image Quality up to flexible 30 fps in all resolution for optimum bandwidth use - Automatic-changeable IR-cut filter with adjustable threshold - Synchronized Two-way Audio - IR working distance up to 15M - IP66 Waterproof Resistance - Optimal Synchronization of Audio and Video - Support Live Video Viewing on Microsoft Live Messenger - Power over Ethernet IEEE 802.3af Class 0 suppliers power to the camera via the network - Digital Input / Output Port for External Alarm & Sensor - Mobile Phone Streaming Live Video through 3GPP / ISMA / RTSP - Mobile Phone Live Image through 2.5 WAP - Multi-level Password Protection for Restricting Camera Access - Built-In Multi-Window Motion Detection (3 detection areas) - Video Buffer makes the Streaming Smoother - UPnP for Fast and Easy Installation - DDNS Supported - Bundled 16 Channel Surveillance Software - User-friendly & Multi-lingual UI

Specification

Image Sensor 1/4” Progressive CMOS Sensor Lens 4.6mm, F1.9 Board Lens System CPU: ARM9 based 32-bit RISC Flash: 8MB SDRAM: 32MB Embedded OS: Linux 2.4 Video Compression MPEG-4, Motion JPEG Adjustable Bitrate (64Kbps to 2048Kbps), Quality and Bitrate Video Resolution Up to 30 frames in all resolutions Video Streaming Simultaneous MPEG-4 & MJPEG (Dual Streaming) Supports Unicast & Multicast Supports 3GPP/ISMA RTSP (Real Time Streaming Protocol) Audio Two-way audio (full duplex) Alarm and Event Built-in multi-window motion detection Input x 1, Output x 1 for External Alarm & Sensor (DIDO) Triggered and scheduled events, Pre- and Post-alarm buffer Supported Protocols TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP, UPnP, RTSP, RTP, HTTP, TCP, UDP, 3GPP/ISMA RTSP Security ID/Password Authentication; SSL Protocol V3.0 Power 12V DC, 1A, Max 6W PoE (Power over Ethernet) Built-in IEEE 802.3af Class 0 Connectors Ethernet – RJ45 for 10/100 Base-T (with PoE) 12V DC Input x 1, Output x 1 for External Alarm & Sensor (DIDO) 3.5mm Audio Input, 3.5mm Audio Output Reset Button Video Surveillance Software Professional surveillance application for viewing, recording and archiving up to 16 cameras Approvals CE, FCC, RoHS Dimension 99mm x 73mm (ö)
