FEATURES:

• Sophisticated Network Functions: remote surveillance, remote playback, remote recording, remote control DVR ;IE embedded .
• Various recording mode: timer, motion detection, alarm, and Recording picture quality, resolution & recording frame rate configurable
• Flexible Display mode : Full Screen, Quad
• Multi-method searching: Time, Recording event (Alarm, motion detection ), recording list
• Triplex : monitoring, recording and playback simultaneously.
• Easy Backup: through network software by scanning HDD and external USB1.1 devices
• Remote View: support IE browser and client software
• Protocol: TCP/IP, DHCP, DDNS, PPPoE
• Support remote menu setup
• Support event log list
• Support multi lever user management, user rights authourized
• Support PTZ control with preset and auto-cruise
• Support USB mouse control
• Support file management, delete or lock every recording file manually
• Support mobile surveillance by smart phones
• Low stream, long recording time. Continueously, real time record a month by 250GB

Category	Description
Video Compression	H.264
Video Inputs	4 BNC
Video Output	2 BNC
VGA Resolution	640X480
Display Resolution	Up to 640x480
Display Frame Rate (Shared)	120 FPS
Playback Resolution	320X240
Record Frame Rate (Shared)	120 FPS
Record Options	Time, Alarm, Motion Detection and Manual
Search Options	Search by Time, Event (Alarm or Motion Detection)
Hard Drive Number/Type Supported	1 HDD ( HDD OPTIONAL)
Audio Inputs/Outputs	2X RCA Audio input and 1XRCA Audio output
USB Port	USB 1.1
USB Support	HD, DVD BURNER, FLASH DRIVE
Ethernet Port	1-RJ45
Remote Monitoring	Internet Explorer
Software Operating System Support	Windows 2000, Windows XP, Windows Vista
RS-485 Port (PTZ Support)	Yes
External Alarm In/Out	4/1
Power Supply	12 V 3 A
Power Consumption	20/42 W (without HD)
Operating Temperature/Humidity	14œF - 131œF, 10%-90%
Dimensions	450mm x 450mm x 95mm
Weight	10 LBS
