16 Channel H.264 Pentaplex Network DVR, 480FPS Realtime Recording, 4 Channel audio input, 16 Channel alarm input,1280*1024 VGA Output, Support D1 Recording, 16 CH Playback, 1 x SATA HDD, Mobile Phone Surveillance, Smaller Form Factor
|
|
LTS LTD7926 16 Ch H.264 Pentaplex Network DVR, 480FPS,D1 Record Mobile Surveillance,
|
Economic16 CH real time CIF recording.
Easy installation and operation, best cost effectiveness
Resolution/frame rate/image quality adjustable per channel; D1 available per channel
Full channel CIF simultaneously playback with audio
Programmable display/spot out/alarm mode
Programmable recording mode with versatile options
Privacy mask\digital zoom\snapshot
Strong log function supported
Powerful remote configuration and maintenance function
Perfect support of IPhone, Blackberry, Google phone, Symbian and Windows mobile
Features for large scale installations
Express backup
SPECIFICATIONS:
| System |
Compression Format |
H.264 |
| OS |
Embedded Linux |
| Video |
Input |
16CH, BNC (1.0Vp-p, 75Ù) |
| Standard Output |
1*BNC Mainout 1*Spot 1*VGA: 1280x1024, 800x600, 1024x768 |
| Audio |
Audio Input |
4CH |
| Audio Output |
1CH |
| Bidirectional Talk |
YES |
| Recording |
D1(4CIF) |
480(NTSC)/400(PAL)fps,
16CH CIF real time |
| CIF |
480(NTSC)/400(PAL)fps |
| Recording Mode |
Schedule, Manual, Motion, Sensor |
| Playback |
Playback Channel |
16CH |
| Search Mode |
Time, Event, File Management,Image(snapshot) |
| Backup |
USB Disk |
1 USB2.0 port |
| DVD Burner |
Optional |
| Backup Format |
DAT or AVI |
| Remote Application |
Dual Stream |
Master stream: 1~25/30fps@4CIF/CIF Network stream: 1~6/7fps@CIF |
| Browser |
IE (windows XP/2000/vista/7) , Safari(Mac OS) |
| Master Stream in Network |
NO |
| CMS |
YES |
| 3G |
SuperCam/pro/HD for iPad/iPad2/iPhone/Blackberry/
Android/Symbian/Windows mobile |
| User Access |
10 users online with professional authority management |
| Alarm |
Alarm Input |
16CH |
| Alarm Output |
1CH |
| Storage |
HDD |
1 SATA HDD up to 2 TB |
| e-SATA |
NO |
| Max HDD after Deploying DVD |
- |
| PTZ |
PTZ |
1*RS485 |
| PTZ Protocol |
PELCOP,PELCOD,LILIN,MINKING,NEON,STAR,VIDO,DSCP,
VISCA,SAMSUNG,RM110,HY |
| Network |
Ethernet |
10 / 100 Mbps Ethernet (RJ-45) |
| Protocol |
TCP/IP, DHCP, DDNS, NTP, SMTP |
| Others |
IR Controller |
Optional |
| Power Supply |
DC12V / 3A |
| Operating Temperature |
0°C ~50°C |
| Humidity |
10% ~ 90% Humidity |
|
Price: $400.00
Buy Product Online | Visit Store Home
|
|
|
Manufactured by LTS |
|
|
|
|
